Amazon EC2 AMI Lifecycle (Part 2)

By Ashwin Venugopal -

 How to launch AWS Ec2 Instance | 2024




Create an Amazon EBS-backed AMI

You can generate your own Amazon EBS-backed AMI from an Amazon EC2 instance or a snapshot of the root volume of an Amazon EC2 instance. To generate an Amazon EBS-backed AMI from an instance, begin by launching an instance using an existing Amazon EBS-backed AMI. This AMI could be one sourced from the AWS Marketplace, made through VM Import/Export, or any other AMI that you have access to. After you modify the instance to suit your particular needs, create and register a new AMI. You can then utilize the new AMI to launch additional instances with your modifications. The AMI creation process is different for instance store-backed AMIs.

Overview of AMI creation from an instance

The steps below outline how to create an Amazon EBS-backed AMI from an active EC2 instance: Begin with an existing AMI, start an instance, personalize it, generate a new AMI from that instance, and ultimately launch an instance using your newly created AMI.

AMI #1: Start with an existing AMI- Find an existing AMI that is similar to the AMI that you'd like to create. This can be an AMI obtained from the AWS Marketplace, an AMI created using VM Import/ Export, or any other AMI that you can access.

Launch instance from existing AMI- The way to configure an AMI is to launch an instance from the AMI on which you'd like to base your new AMI, and then customize the instance. Then, you'll create a new AMI that includes the customizations.

EC2 instance #1: Customize the instance- Connect to your instance and customize it for your needs. Your new AMI will include these customizations. You can perform any of the following actions on your instance to customize it:

Install software and applications

Copy data

Reduce start time by deleting temporary files and defragmenting your hard drive

Attach additional EBS volumes

Create image- When you create an AMI from an instance, Amazon EC2 powers down the instance before creating the AMI to ensure that everything on the instance is stopped and in a consistent state during the creation process. During the AMI-creation process, Amazon EC2 creates snapshots of your instance's root volume and any other EBS volumes attached to your instance. Depending on the size of the volumes, it can take several minutes for the AMI-creation process to complete (sometimes up to 24 hours). You might find it more efficient to create snapshots of your volumes before creating your AMI. This way, only small, incremental snapshots need to be created when the AMI is created, and the process completes more quickly (the total time for snapshot creation remains the same).

AMI #2: New AMI- After the process completes, you have a new AMI and snapshot created from the root volume of the instance. If you added instance-store volumes or EBS volumes to the instance, in addition to the root device volume, the block device mapping for the new AMI contains information for these volumes.

Launch instance from new AMI- You can use the new AMI to launch an instance.

EC2 instance #2: New instance- When you launch an instance using the new AMI, Amazon EC2 creates a new EBS volume for the instance's root volume using the snapshot. If you added instance-store volumes or EBS volumes when you customized the instance, the block device mapping for the new AMI contains information for these volumes, and the block device mappings for instances that you launch from the new AMI automatically contain information for these volumes. The instance-store volumes specified in the block device mapping for the new instance are new and don't contain any data from the instance store volumes of the instance you used to create the AMI. The data on EBS volumes persists.

When you create a new instance from an EBS-backed AMI, you should initialize both its root volume and any additional EBS storage before putting it into production.

Conclusion

Amazon EBS-backed AMI is created with the help of above methods.
